The Piaf is a compact and nimble monohull sailboat, primarily known as a recreational dinghy, designed by Philippe Staempfli. With an overall length of just over 12 feet, it was conceived as an accessible sailing craft, appealing to those seeking simple day sailing or learning experiences. The Piaf's legacy is closely tied to its builder, Spair Marine, a French company that aimed to bring sailing to a broader audience through approachable designs during the mid-to-late 20th century.
Piaf Information, Review, Specs
- Make
- Model
- Number Built
- Production Year(s)
- 1965 - 1980
The Piaf's production history spans from 1965 to 1980, marking it as a popular small sailboat of its era. The initial version of the Piaf, featuring a daggerboard, was first built by Staem-Marine. However, it was a more popular iteration, introduced by Spair Marine in 1970, that solidified its presence in the recreational sailing market. This collaboration with designer Philippe Staempfli and the builder's ethos of creating accessible designs likely guided the Piaf's development. Spair Marine, known for focusing on specific segments of the sailing market with smaller, dinghy-style boats, ensured the Piaf aligned with the needs of coastal and inland water sailors. The evolution from a daggerboard to a centerboard in the more popular Spair version suggests a design refinement aimed at enhancing usability, particularly in shallow waters and for easier beaching.
Sailing Performance and Handling
As a 12-foot monohull dinghy with a lightweight displacement of 276 lbs, the Piaf is characterized by its responsive and lively handling. Its design, featuring a centerboard, provides flexibility for navigating varying depths, allowing for a shallow draft of 0.56 feet with the board up and a maximum draft of 3.05 feet when fully deployed. This makes the Piaf particularly well-suited for exploring shallow coastal areas or small lakes. The fractional sloop rig contributes to ease of handling, making it a suitable boat for both new sailors learning the ropes and experienced enthusiasts looking for a straightforward day sailer. The light displacement and 89 square feet of reported sail area suggest a boat that would be quick to accelerate in light to moderate breezes, offering an engaging sailing experience.
Accommodations and Layout
Given its compact size, the Piaf's interior accommodations are minimal, typical of a day-sailing dinghy. It features an open cockpit design, prioritizing sailing functionality and deck space over enclosed living areas. While specific interior layouts are not readily available, boats of this type generally offer bench seating, providing comfortable space for a few occupants during a day trip. Storage would likely be limited to small compartments or bags for personal gear. The emphasis is on a simple, uncluttered setup, reinforcing its purpose as an accessible and easy-to-manage recreational sailboat.
Measurements
Construction & Hull
- Construction Material
- Fiberglass (Solid)
- Hull Type
- Monohull Sailboat
- Keel Type
- Centerboard
- Rudder
- 1x —
- Ballast
- -
- Displacement
- 276 lbs
- Water Capacity
- -
- Fuel Capacity
- -
Engine
- Engine Make
- —
- Engine Model
- —
- Engine Type
- —
- Engine HP
- —
- Engine Count
- 1
- Drive Type
- —
- Fuel Type
- —
Rig & Sails
- Rig Type
- Fractional Sloop
- P (Main Luff)
- -
- E (Main Foot)
- -
- I (Foretriangle Height)
- -
- J (Foretriangle Base)
- -
- Forestay Length (est)
- -
- Main Sail Area
- -
- Foretriangle Sail Area
- -
- Total Sail Area (Reported)
- 89 sqft
- Total Sail Area (Calc)
- -
Dimensions
- LOA
- 12.3 ft
- LWL
- 10.99 ft
- Beam
- 5.41 ft
- Draft
- 3.05 ft
- Max Headroom
- -
- Air Draft
- -
Calculations
- Hull Speed
- 4.44 kn
- Pounds per Inch Immersion
- 212.44
