The Nautor Swan 57 CC (Frers) is a distinguished sailing yacht, conceived for discerning owners seeking a harmonious blend of luxurious comfort and robust bluewater performance. Designed by the renowned naval architect Germán Frers and meticulously crafted by the esteemed Finnish builder Nautor's Swan, this model represents a refined vision of long-distance cruising. With its substantial displacement and sophisticated design, the Swan 57 CC is celebrated for its timeless elegance and impressive seaworthy capabilities, making it a formidable vessel for extended voyages and serious cruising enthusiasts alike.
Swan 57 CC (Frers) Information, Review, Specs
- Make
- Frers
- Model
- Swan 57 CC
- Number Built
- 5
- Production Year(s)
- 1990 - 1997
The genesis of the Swan 57 CC (Frers) spans from 1990 to 1997, during which only five of these exclusive vessels were built. This model emerged as a notable variation of the earlier Swan 55 CC (Frers), distinguished by its elegantly extended reverse transom, a design feature that both enhanced its aesthetics and potentially improved its waterline length and performance characteristics. Germán Frers, whose enduring partnership with Nautor's Swan began in 1983, became the principal naval architect responsible for defining the modern era of Swan yachts, consistently pushing the boundaries of performance and luxury. The Swan 57 CC embodies Frers' philosophy of crafting yachts that achieve a harmonious blend of aesthetics, functionality, and seaworthiness.
During the period of its production, Nautor's Swan maintained an unwavering commitment to excellence, a hallmark of their manufacturing ethos. The Finnish builder was (and remains) globally recognized for its exquisite build quality, exhilarating performance, and timeless design. Their approach combined robust construction with supreme comfort and capabilities suitable for serious bluewater cruising, an identity that is clearly reflected in the design and construction of the Swan 57 CC.
Sailing Performance and Handling
The Swan 57 CC (Frers) is equipped with a masthead sloop rig and features a fin keel with a spade rudder, a configuration chosen to optimize both performance and responsiveness. Analyzing its key performance ratios provides insight into its sailing characteristics. With a Sail Area to Displacement (SA/Disp) ratio of approximately 15.45, the Swan 57 CC exhibits a balanced performance profile, suggesting it will be competent in a range of wind conditions, providing solid cruising speeds without being overtly focused on light-air racing.
Its Ballast to Displacement (Bal/Disp) ratio stands at around 38.3%. While slightly below the 40% often associated with exceptionally stiff bluewater boats, this figure still indicates a substantial amount of ballast relative to its overall weight, contributing to good initial stability and the ability to stand up to a fair breeze. The Displacement to Length (D/L) ratio, calculated at approximately 294, places the Swan 57 CC firmly in the category of a heavier displacement cruiser. This translates to a comfortable and stable motion in a seaway, prioritizing comfort and seaworthiness over extreme speed, making it well-suited for long-distance passages. Owners and reviewers often laud the Swan 57 CC for its "seaworthy performance," underscoring its capability to handle various ocean conditions with grace and confidence.
Accommodations and Layout
While specific interior details can vary, the Swan 57 CC (Frers) is often configured with a "Family Cruiser" interior layout designed for spaciousness and liveability. The interior is engineered to be fully usable even while at sea, emphasizing practical comfort for extended voyages. A prominent feature of the layout is a generous aft owner's stateroom, typically featuring an offset double berth, providing a private and comfortable sanctuary. In addition to the owner's suite, a VIP cabin is usually present, offering ample accommodation for guests.
Although the maximum headroom is not specified in the provided data, a yacht of this size is expected to offer generous standing room throughout the main living areas. Nautor's Swan yachts of this era are renowned for their high-quality finishes, typically incorporating fine wood trim, robust joinery, and well-integrated fiberglass components. Attention to detail in the construction ensures durability and a luxurious ambiance. Storage is generally abundant, crucial for bluewater cruising, and ventilation is typically well-considered to ensure comfort in various climates.
Owner's Perspectives
Due to the limited production run of only five vessels, widely documented owner reviews specifically for the Swan 57 CC (Frers) are not extensively available. However, based on the broader reputation of Nautor's Swan, owners of these yachts consistently praise their solid construction, the exquisite craftsmanship that goes into every detail, and the comfortable, secure motion they offer in a seaway. The enduring quality and design of Swan yachts often lead to high owner satisfaction, with many appreciating the blend of luxurious living spaces and true sailing capability.
General feedback on Nautor's Swan vessels from the 1990s often highlights the longevity of their construction and systems, though like any yacht of this vintage, periodic maintenance, particularly concerning items like teak decks and original equipment, is a consideration. The engine specified for the Swan 57 CC is a Perkins M135, which is a robust and reliable choice for a yacht of this displacement. Owners typically value the support offered by the global Nautor Swan community and services, ensuring the continued enjoyment and maintenance of these prized vessels.
Measurements
Construction & Hull
- Construction Material
- Fiberglass (Solid)
- Hull Type
- Monohull Sailboat
- Keel Type
- Fin
- Rudder
- 1x Spade
- Ballast
- 19910 lbs (Lead)
- Displacement
- 52030 lbs
- Water Capacity
- 232 gal
- Fuel Capacity
- 164 gal
Engine
- Engine Make
- Perkins
- Engine Model
- M135
- Engine Type
- —
- Engine HP
- —
- Engine Count
- 1
- Drive Type
- —
- Fuel Type
- Diesel
Rig & Sails
- Rig Type
- Masthead Sloop
- P (Main Luff)
- -
- E (Main Foot)
- -
- I (Foretriangle Height)
- -
- J (Foretriangle Base)
- -
- Forestay Length (est)
- -
- Main Sail Area
- -
- Foretriangle Sail Area
- -
- Total Sail Area (Reported)
- 1350 sqft
- Total Sail Area (Calc)
- -
Dimensions
- LOA
- 57 ft
- LWL
- 42.87 ft
- Beam
- 15 ft
- Draft
- 7.2 ft
- Max Headroom
- -
- Air Draft
- -
Calculations
- Hull Speed
- 8.77 kn
- Pounds per Inch Immersion
- 2
